1. Adopt industrial-grade LCD panel;
2. Adopt the latest color correction technology and unique wide viewing angle processing technology;
3. Integrated intelligent channel cruise function;
4. RC intelligent adaptive digital processing technology;
5. Instantaneous image, still image function;
6. Intelligent automatic image removal technology;
7. Intelligent temperature control cooling function.
Tel : 400-772-9685
Let's start talkingWelcome to contact us for product consultation.
Industrial grade DID- FHD LED panels, low energy consumption, better stability,stronger contrast, shows images of beautiful color, better restore, layering is more prominent.
●Skyworth V12 patent image processing technology
With the advanced digital high-speed image processing technology, the video bandwidth is as high as 500MHZ; the input image signals are split and amplified in a real-time manner during computation; on the single-screen picture after multiple-time splitting and amplification, the problem of jaggy and mosaic phenomena brought by A/D conversion is thoroughly solved.
●3D HD digital image processing technology
The 3D Digital Comb Filter and 3D digital image noise reduction technology is greatly reducing clutter detail images, the edges jagged.
●RC adaptive control
According to the amplitude of the luminance signal, the function can improve different contents, make the image a sense of depth, reduce the black noise, improve contrast, and enhance the image deep sense.
●H2S Wide Dynamic technology
It can process HD video signal under different frequency, and solve image flicker.
●Intelligent automatic afterimage technique
Protecting the long term use of LCD with automatic elimination of blur function.
●Intelligent backlight control function
Intelligent Sensing environments and real image of light intensity, you can automatically adjust the LCD screen backlight glow.
Brightness and the brightness and contrast of the image.
●Regional amplification
Regional image magnification.
●Dynamic contrast ratio function
Promote dynamic contrast technology, combined with intelligent backlight control technology, can makeLike a dynamic contrast ratio of up to 5 million: 1, so as to further enhance the image view deeper feeling.
●Intelligent temperature control and cooling function
When the internal temperature reaches the set limit temperature, the cooling fan will start automatically to sink heat; when the temperature is out of range, it will alarm.
●High reliability, high stability, long service life
Using industrial-grade power supply modules, pure hardware design, startup speed, stable and reliable system, more than 60,000 hours of uninterrupted work.
| Model | H46PJTF-LB | |
| Splicing gap | ≤3.5mm | |
| Splicing combinations | Any arbitrary row × column | |
| A liquid crystal panel | Resolution | 1920×1080 8Bit |
| Dimension | 1021.98(W)×576.57(H)mm | |
| Effective display range | 1018.08(H)×572.67(V)mm | |
| Standard colors | 16.7M | |
| Type | DID FHD-LED | |
| Brightness | 500cd/m2 | |
| Contrast | 3500:1 | |
| Response Time | 8ms | |
| Viewing Angle | 178° | |
| Signal Interface | Input interface | VGA×1，HDMI×1，DVI×1，CVBS×1 |
| Output interface | CVBS×1,DVI×1 | |
| USB input | 1channel：USB2.0 support update online | |
| Communication interface | RS485 In/Out DP,SDI,S-video,IP,TVI | |
| Selection interface | ||
| Power | AC100 ～ 240V,50/60Hz | |
| Maximum power consumption | 140W | |
| Work Environment | Temperature | 0℃～ 50℃ |
| Relative humidity | 10％～ 90％ | |
